TPLINK CCTV VIGI C540 4MP 4MM FULL-COLOR PT (PAN & TILT) NETWORK CAMERA
Product SKU TL-VIGI C540HP-4
Brand TP-LINK
Availability
Description

VIGI 4MP Outdoor Full-Color Pan Tilt Network Camera - VIGI C540

4MP High Definition - The camera comes with 4MP-more than enough pixels to pick up some of the more discrete details.

24h Full-Color - Obtain 24-hour color details, even in pitch-black conditions, via high-sensitivity sensor and included spotlight LEDs.

Powerful Pan Tilt - Customized patrol routes and auto tracking provide more intelligent options to monitor key areas and improve security within your property.

Waterproof - Reliable IP66 for stable outdoor performance.

Smart Detection (human detection, motion detection, area intrusion, line-crossing, video tampering) - Receive notifications and check feeds when someone crosses a boundary, enters an area you've set, or obstructs the camera.

H.265+ - Without using any extra bandwidth, your cameras transmit compressed crystal-clear video to save disk space, ease network loads, and reduce monitoring costs without sacrificing image quality.

PoE/12V DC - Two power supply ways not only give you more convenience but also make your wiring remarkably easy.

VIGI App - Manage your security from the palm of your hand with the VIGI app.

Specifications

Network

Security Password Protection, HTTPS Encryption, IP Address Filter, Digest Authentication
Protocol TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS
API ONVIF
Simultaneous Live View 3 Main Streams & 3 Sub-Streams

General

Package Contents VIGI Network Camera
Quick Start Guide
Waterproof Cable Attachments
Mounting Accessories (Screws, Drywall Anchors, Hex Key)
Operating Temperature -30–60 °C
Certifications CE, RCM, BSMI, VCCI, RoHS, NTRA, KC
Dimensions( H X W X D ) 120 × 172 × 198 mm
Material Plastic
Weight 195g
General Features Two Streams, Mirror, Privacy Masks, Password Reset via E-mail, HTTP Listening
Power Requirements 12V DC ± 5%, 5.5mm Coaxial Power Plug
PoE (802.3af/at, class 0)

Camera

Image Sensor 1/3” Progressive Scan CMOS
Lens Fixed focal lens (4 mm)
Aperture 4 mm: F1.6
Lens Mount M12
Viewing Angle (4mm) Horizontal FOV: 79°, Vertical FOV: 43°, Diagonal FOV: 93°
Digital Zoom Yes
Day/Night Mechanism IR Cut Filter
IR Working Distance 30m
Illumination Distance 30 m
Minimum Illumination 0 lux with IR/white Light
Pan/Tilt Range Pan: 0° to 350°, Tilt: 0° to 120°
Weatherproof Rating IP66
Digital Noise Reduction 3D DNR
WDR DWDR

Videeo/Image

Video Compression Main stream: H.265+/H.265/H.264+//H.264
Sub-Stream: H.265/H.264
Frame Rate & Resolutions Main Stream
Frame Rate: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps
Resolution: 2560x1440, 2304x1296, 2048x1280, 1920x1080

Sub-Stream
Frame Rate: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps
Resolution: 640x480, 352x288, 320x240
Video Streaming Main Stream
Sub-Stream
Image Settings Mirror, Brightness, Contrast, Saturation, Sharpness, Exposure, WDR, White Balance Adjustable by Client Software
Image Enhancement BLC/3D DNR/Prevent Overexposure to Infrared Light
Video Bit Rate Main Stream: 256 Kbps to 4 Mbps
Sub-Stream: 64 Kbps to 512 Kbps

Smart Feature-Set

Smart Event Area Intrusion Detection, Line-Crossing Detection, Human Detection
Basic Event Motion Detection, Camera Tampering Detection, Exception ( illegal login)
Linkage Method Trigger Notification: ONVIF, HTTPS
Region of Interest 1 Region

Interfaces

Network Interface 1 RJ45 10/100M Self-Adaptive Ethernet Port
Audio Input Built-in Microphone
Audio Output Built-in Speaker
Button Reset Button
Slot Micro SD card



Warranty Limited 2-year warranty
